Titanic
Using the Titanic dataset from Kaggle. I'm building this notebook after completing chapter 2 of Hands on Machine Learning, which covers how to complete an end-to-end machine learning project.
Frame the problem
Objective: use machine learning to create a model that predicts which passengers survived the Titanic shipwreck.
It seems some groups of people were more likely to survive than others.
Answer the question: "what sorts of people were more likely to survive?" using passenger data (e.g. name, age, gender, socio-economic class, etc.).
Get the data
Datasets
1) train.csv: subset of passengers (n=891) for training.
The value in the column Survived indicate whether the passenger survived or not (survived=1, died=0).
2) test.csv: subset of passengers for testing (n=418).
3) gender_submission.csv: example to show how you should structure your predictions. It predicts that all female passengers survived, and all male passengers died.
Your submission file should contained a PassengerID column (containing the ID of each passenger from test.csv) and a Survived column, where survived=1 and died=0.
# Creata dataframes from CSV files
import pandas as pd
import numpy as np
train = pd.read_csv('datasets/train.csv')
test = pd.read_csv('datasets/test.csv')
gender_submission = pd.read_csv('datasets/gender_submission.csv')
train.head()
test.head()
gender_submission.head()
Examine the data
train.shape
train.info()
# Examine categorical variables
train['Sex'].value_counts()
train['Ticket'].value_counts() # Not sure if this is valuable for the model
train['Cabin'].value_counts() # Not sure if this is valuable for the model
train['Embarked'].value_counts() # Might be useful, probably needs one-hot encoding
# Examine numerical variables
train.describe()
# See numerical variable distributions
train.hist(bins=50, figsize=(20, 15))
Observations on the data:
Many numerical variables are really more categorical. So, we should One-Hot or Ordinal Encoding to transform them before training our model (Ordinal: Pclass, SibSp, Parch).
Fare and Age have very different scales, we can fix this using feature scaling.
Fare and Age are also fairly tail-heavy. Can we transform them to have more bell-shaped distributions?
PassengerId should not be used for training, seems pretty useless.
We do not need to create a test set, one has already been created for us: test.csv
Normally if I were to create a test set, I'd attempt to do some sort of stratified sampling along a single variable to make sure there was an equal distribution of that variable in both train and test datasets (note: attempting to stratify based on multiple variables would be overly complex - StackExchange and Scribbr)
Explore the data to gain insights
Potential ways to conduct exploratory data analysis:
Create boxplot/violinplot/swarmplot of different numerical attributes for different classes of the target variable. This helps identify potential relationships and dependencies that could impact the target.
# Start by setting aside the test set to make sure we're only working w/ training data
titanic = train.copy()
# Looking for correlations
corr_matrix = titanic.corr()
corr_matrix['Survived'].sort_values(ascending=False)
Looks like Fare and Pclass are actually highly positively and negatively correlated with Survived, respectively.
These variables are actually quite similar. Fare is the price of the ticket, and Pclass is the class of the ticket (lower number --> higher class). Does this mean the richest passengers were more likely to survive?
# Visualize the correlation between attributes
from pandas.plotting import scatter_matrix
attributes = ['Survived', 'Fare', 'Parch', 'SibSp', 'Age', 'Pclass']
scatter_matrix(titanic[attributes], figsize=(12, 8))
This visualization really isn't so useful because the target attribute is binary, which makes it quite difficult to tease out any real pattern.
# Barplot to visualize distribution of categorical attribute for different classes of target
import seaborn as sns
import matplotlib.pyplot as plt
def cat_countplot(attribute, tight=False):
sns.countplot(data=titanic, x=attribute, hue='Survived')
if tight:
plt.xticks(rotation=45, ha='right')
plt.tight_layout()
cat_countplot('Sex')
cat_countplot('Pclass')
cat_countplot('Parch')
cat_countplot('SibSp')
It looks like having either one parent/child on the boat, or one sibling/spouse on the boat makes it more likely for the passenger to survive. Maybe that's because smaller families were easier to fit onto the lifeboats. And if an entire family couldn't fit on the lifeboat, then they didn't want to leave anyone behind (so they all stayed on the boat).
# Boxplot to visualize numerical variables
def num_boxplot(attribute):
sns.boxplot(data=titanic, x='Survived', y=attribute)
num_boxplot('Fare')
num_boxplot('Age')
Attribute combinations
Family = Parch + SibSp
# Create new attribute
titanic['Family'] = titanic['Parch'] + titanic['SibSp']
titanic[(titanic['Parch']>0) & (titanic['SibSp']>0)].head()
# Updated correlation matrix
corr_matrix = titanic.corr()
corr_matrix['Survived'].sort_values(ascending=False)
cat_countplot('Family')
Although the correlation between Survived and Family is not as high as I thought it would be, it still seems like passengers who had families that weren't too big (more than four parents/children/sibling/spouses) were more likely to survive. Is there a strong relationship between Family and other attributes that have high correlation with Survived? Like Fare or Pclass?
corr_matrix['Family'].sort_values(ascending=False)
There is a slight positive correlation between Family and Fare. Meaning passengers with higher fares are more likely to have larger families. And passengers with higher fares are more likely to survive.
Is it possible to extract titles from passenger names? And compare survival rates between different title classes?
titanic['Title'] = titanic['Name'].str.extract(', ([A-Za-z]+)\.', expand=False)
titanic['Title'].value_counts()
cat_countplot('Title', tight=True)
We know that women were more likely to survive than men. However, it's interesting to look at the Title value of 'Master'. I'm assuming this is the one category of men who were more likely to survive than not. More likely than not they were wealthier passengers with higher fares/classes.
Prepare the data
# Separate targets from training data
titanic = train.drop('Survived', axis=1)
titanic_labels = train['Survived'].copy()
titanic.columns
# Let's separate numerical and categorical attributes first
num_columns = titanic.select_dtypes(include=['number']).columns.tolist()
cat_columns = titanic.select_dtypes(exclude=['number']).columns.tolist()
titanic_num = titanic[num_columns]
titanic_cat = titanic[cat_columns]
print(f"""
Num colums: {num_columns}
Cat columns: {cat_columns}""")
Data cleaning
# Find attributes w missing data
titanic.info()
Attributes w/ missing data:
Age (714 non-null) --> can impute these missing values, age is likely an important attribute to include.
Cabin (204 non-null) --> probably best to drop this column entirely, there's too much missing data
Embarked (889 non-null) --> can impute these missing values, there's only 2 missing.
# Impute missing values for numerical data
from sklearn.impute import SimpleImputer
# Mean and median for Age column are very close, shouldn't make a major difference
imputer = SimpleImputer(strategy='median')
imputer.fit(titanic_num)
# To see the medians calculated for each column
imputer.statistics_
# Create transformed dataframe
X = imputer.transform(titanic_num)
titanic_num_tr = pd.DataFrame(X, columns=titanic_num.columns, index=titanic_num.index)
# Impute missing values for categorical data
# Since there are only two missing values for Embarked, let's start w/ mode imputation
imputer = SimpleImputer(strategy='most_frequent')
imputer.fit(titanic_cat)
X = imputer.transform(titanic_cat)
titanic_cat_tr = pd.DataFrame(X, columns=titanic_cat.columns, index=titanic_cat.index)
# Encoding for categorical attributes
# Can more easily accomplish this with pd.get_dummies() instead of OneHotEncoder
dummy_variables = pd.get_dummies(titanic_cat_tr[['Sex', 'Embarked']])
titanic_cat_tr = pd.concat([titanic_cat_tr, dummy_variables], axis=1)
titanic_cat_tr.head()
Create custom transformers
Transformations I want to accomplish:
Add Family column = SibSp + Parch
Add Title column --> extracted from Name
Remove columns: PassengerId, Name, Ticket, Cabin
# Create custom transformer
from sklearn.base import BaseEstimator, TransformerMixin
import re
# Column indexes for variables
def get_col_index(col):
index = train.columns.get_loc(col)
return index
cols = ['PassengerId', 'Survived', 'Name', 'Ticket', 'Cabin', 'SibSp', 'Parch']
indices = [get_col_index(col) for col in cols]
passengerid_ix, survived_ix, name_ix, ticket_ix, cabin_ix, sibsp_ix, parch_ix = indices
class AttributesAdder(BaseEstimator, TransformerMixin):
def __init__(self, add_family=True, add_title=True):
self.add_family = add_family
self.add_title = add_title
def fit(self, X, y=None):
return self
def transform(self, X, y=None):
family = X[:, sibsp_ix] + X[:, parch_ix]
title_extract = lambda name: re.search(', ([A-Za-z]+)\.', name).group(1) if re.search(', ([A-Za-z]+)\.', name) else None
get_title = np.vectorize(title_extract)
title = get_title(X[:, name_ix].astype(str))
if self.add_family:
X = np.c_[X, family]
if self.add_title:
X = np.c_[X, title]
remove_col_indices = passengerid_ix, name_ix, ticket_ix, cabin_ix
X = np.delete(X, remove_col_indices, axis=1)
return X
attr_adder = AttributesAdder(add_family=True, add_title=True)
attr_adder.transform(train.values)
Transformation pipelines
We need two separate pipelines, one for numerical columns and one for categorical columns.
print(f"""
All columns: {titanic.columns}
Numerical columns: {num_columns}
Categorical columns: {cat_columns}
""")
# Let's rewrite a separate custom transformer just for numerical attributes
passengerid_ix, pclass_ix, age_ix, sibsp_ix, parch_ix, fare_ix = 0, 1, 2, 3, 4, 5
class NumTransformer(BaseEstimator, TransformerMixin):
def __init__(self, add_family=True):
self.add_family = add_family
def fit(self, X, y=None):
return self
def transform(self, X, y=None):
if self.add_family:
family = X[:, sibsp_ix] + X[:, parch_ix]
X = np.c_[X, family]
X = np.delete(X, passengerid_ix, axis=1)
return X
# And another one for categorical attributes
name_ix, sex_ix, ticket_ix, cabin_ix, embarked_ix = 0, 1, 2, 3, 4
class TitleAdder(BaseEstimator, TransformerMixin):
def __init__(self, add_title=True):
self.add_title = add_title
def fit(self, X, y=None):
return self
def transform(self, X, y=None):
if self.add_title:
title_extract = lambda name: re.search(', ([A-Za-z]+)\.', name).group(1) if re.search(', ([A-Za-z]+)\.', name) else None
get_title = np.vectorize(title_extract)
title = get_title(X[:, name_ix].astype(str))
X = np.c_[X, title]
remove_col_indices = name_ix, ticket_ix, cabin_ix
X = np.delete(X, remove_col_indices, axis=1)
return X
from sklearn.pipeline import Pipeline
from sklearn.compose import ColumnTransformer
from sklearn.preprocessing import OneHotEncoder
from sklearn.preprocessing import StandardScaler
# Main steps: impute missing values, column transformations, feature scaling
# Numerical pipeline
num_pipeline = Pipeline([
('imputer', SimpleImputer(strategy='median')),
('num_transformer', NumTransformer()),
('std_scaler', StandardScaler())
])
# Categorical pipeline
cat_pipeline = Pipeline([
('imputer', SimpleImputer(strategy='most_frequent')),
('title_adder', TitleAdder()),
('one_hot_encoder', OneHotEncoder(handle_unknown='ignore'))
])
# Combine the numerical and categorical pipelines
full_pipeline = ColumnTransformer([
('num', num_pipeline, num_columns),
('cat', cat_pipeline, cat_columns)
])
titanic_prepared = full_pipeline.fit_transform(titanic)
# Get categories from One Hot Encoder
cat_encoder = full_pipeline.named_transformers_['cat']
cat_encoder_feature_names = cat_encoder.named_steps['one_hot_encoder'].get_feature_names_out(['Sex', 'Embarked', 'Title'])
cat_one_hot_attribs = list(cat_encoder_feature_names)
cat_one_hot_attribs
Final columns after full pipeline transformation:
Numerical: Pclass, Age, SibSp, Parch, Fare, Family (extra)
Categorical: Sex, Embarked, Title (extra)
One-Hot encoded: (above)
final_attribs = ['Pclass', 'Age', 'SibSp', 'Parch', 'Fare', 'Family'] + cat_one_hot_attribs
final_attribs
Explore many different models
Different models to try: Logistic Regression, Decision Tree, Random Forest
# Utility function for model evaluation
def display_scores(scores):
print('Scores:', scores)
print('Mean:', scores.mean())
print('Standard Deviation:', scores.std())
# Logistic Regression
from sklearn.linear_model import LogisticRegression
from sklearn.metrics import accuracy_score
from sklearn.model_selection import cross_val_score
import os
import joblib
# Directory to store models
os.makedirs('models', exist_ok=True)
# logreg = LogisticRegression()
# logreg.fit(titanic_prepared, titanic_labels)
# joblib.dump(logreg, 'models/logreg.joblib')
logreg = joblib.load('models/logreg.joblib')
titanic_predictions = logreg.predict(titanic_prepared)
logreg_accuracy = accuracy_score(titanic_labels, titanic_predictions)
logreg_accuracy
# Cross-validation on Logistic Regression
# Using accuracy as evaluation metric for now
logreg_scores = cross_val_score(
logreg, titanic_prepared, titanic_labels, scoring='accuracy', cv=10
)
display_scores(logreg_scores)
Logistic regression:
Training set accuracy score: 83.1%
Mean cross-validation accuracy: 82.6%
Seems to perform very well on validation sets, meaning we're not overfitting.
# Decision Tree
from sklearn.tree import DecisionTreeClassifier
# tree = DecisionTreeClassifier()
# tree.fit(titanic_prepared, titanic_labels)
# joblib.dump(tree, 'models/tree.joblib')
tree = joblib.load('models/tree.joblib')
titanic_predictions = tree.predict(titanic_prepared)
accuracy_score(titanic_labels, titanic_predictions)
# Cross-validation on Logistic Regression
tree_scores = cross_val_score(
tree, titanic_prepared, titanic_labels, scoring='accuracy', cv=10
)
display_scores(tree_scores)
Decision tree classifier:
Training set accuracy score: 98.2%
Mean cross-validation accuracy: 77.7%
We're badly overfitting using a decision tree.
# Random Forest
from sklearn.ensemble import RandomForestClassifier
# forest = RandomForestClassifier()
# forest.fit(titanic_prepared, titanic_labels)
# joblib.dump(forest, 'models/forest.joblib')
forest = joblib.load('models/forest.joblib')
titanic_predictions = forest.predict(titanic_prepared)
accuracy_score(titanic_labels, titanic_predictions)
# Cross validation
forest_scores = cross_val_score(
forest, titanic_prepared, titanic_labels, scoring='accuracy', cv=10
)
display_scores(forest_scores)
Random forest classifier:
Training set accuracy score: 98.2%
Mean cross-validation accuracy: 80.9%
Random forest is still overfitting, but not as bad as the decision tree, and it gets fairly close to the logistic regression mean cross-validation score of 82.6%.
Fine-tune your models
Let's work with our Random Forest model going forward, this was the most promising. Let's use Randomized Search to perform hyperparameter tuning.
from sklearn.model_selection import RandomizedSearchCV
param_grid = {
'n_estimators': np.arange(100, 1000, 100),
'max_depth': [None, 5, 10, 20],
'max_features': ['sqrt', 'log2'],
'bootstrap': [True, False]
}
forest = RandomForestClassifier()
rnd_search = RandomizedSearchCV(
forest,
param_distributions=param_grid,
n_iter=50,
cv=5,
scoring='accuracy',
verbose=2,
random_state=42
)
# rnd_search.fit(titanic_prepared, titanic_labels)
# joblib.dump(rnd_search, 'models/forest_rnd_search.joblib')
rnd_search = joblib.load('models/forest_rnd_search.joblib')
# Get the best parameters and best score
best_params = rnd_search.best_params_
best_score = rnd_search.best_score_
# Print the best parameters and best score
print("Best Parameters: ", best_params)
print("Best Score: ", best_score)
# Feature importances
feature_importances = rnd_search.best_estimator_.feature_importances_
sorted(zip(feature_importances, final_attribs), reverse=True)
# Creating new transformer in preparation pipeline to only select the most important attributes
def indices_of_top_k(arr, k):
return np.argsort(arr)[-k:]
class TopFeatureSelector(BaseEstimator, TransformerMixin):
def __init__(self, feature_importances, k):
self.feature_importances = feature_importances
self.k = k
def fit(self, X, y=None):
self.feature_indices_ = indices_of_top_k(self.feature_importances, self.k)
return self
def transform(self, X):
return X[:, self.feature_indices_]
k = 5
top_k_feature_indices = indices_of_top_k(feature_importances, k)
top_k_feature_indices
np.array(final_attribs)[top_k_feature_indices]
# Double check that these are indeed the top k features
sorted(zip(feature_importances, final_attribs), reverse=True)[:k]
# Create a new pipeline that runs previously defined prep pipeline and adds top k feature selection
# Also, build in prediction
prepare_select_and_predict_pipeline = Pipeline([
('preparation', full_pipeline),
('feature_selection', TopFeatureSelector(feature_importances, k)),
('forest_classifier', RandomForestClassifier(**rnd_search.best_params_))
])
prepare_select_and_predict_pipeline.fit(titanic, titanic_labels)
# Try the full pipeline
some_data = titanic.iloc[:4,]
some_labels = titanic_labels[:4]
print("Predictions:\t", prepare_select_and_predict_pipeline.predict(some_data))
print("Labels:\t\t", list(some_labels))
# Explore preparation options using GridSearchCV
from sklearn.model_selection import GridSearchCV
param_grid = [
{
'feature_selection__k': list(range(1, len(feature_importances) + 1))
}
]
grid_search_prep = GridSearchCV(
prepare_select_and_predict_pipeline,
param_grid,
cv=5,
scoring='accuracy',
verbose=2
)
# grid_search_prep.fit(titanic, titanic_labels)
# joblib.dump(grid_search_prep, 'models/grid_search_prep.joblib')
grid_search_prep = joblib.load('models/grid_search_prep.joblib')
grid_search_prep
grid_search_prep.best_params_
rnd_search.best_params_
Final parameters for model
Using Random Forest Classifier:
Best Parameters: {'n_estimators': 100, 'max_features': 'log2', 'max_depth': 5, 'bootstrap': True}
{'feature_selection__k': 8} --> update k=8 in prepare_select_and_predict_pipeline
# Updating full pipeline
prepare_select_and_predict_pipeline = Pipeline([
('preparation', full_pipeline),
('feature_selection', TopFeatureSelector(feature_importances, 8)),
('forest_classifier', RandomForestClassifier(**rnd_search.best_params_))
])
prepare_select_and_predict_pipeline.fit(titanic, titanic_labels)
Generate predictions on test set
predictions = prepare_select_and_predict_pipeline.predict(test)
# Ensure we have enough predictions
print(f"""
Shape of test set: {test.shape}
Number of predictions: {len(predictions)}
""")
# Combine PassengerID and predictions
predictions = pd.DataFrame(predictions, columns=['Survived'])
test_passenger_ids = test['PassengerId'].copy()
submission = pd.concat([test_passenger_ids, predictions], axis=1)
submission.head()
submission.shape
submission.info()
submission.to_csv('submission.csv', index=False)
